| FPGA Development Platforms for VLSI Laboratory |
| |
| “VLSI & Embedded Systems“ knowledge has become a necessity in every Engineer’s skill sets, due to the establishment of Design house by global EDA vendors & Semiconductor industries in India. Last few years, the industry has witnessed tremendous growth due to |
| |
 |
Change in Technology (Sub-micrometer to Sub-nanometer technology) |
|
Availability of sophisticated software tools for modeling, simulation, design, Prototype, Verification and Validation |
|
Time to market constraints |
|
Ever growing user requirements driving innovative product solutions. |
|
|
|
| |
| The industry is constantly looking for skilled Engineers/ technicians to handle the challenges and expect technical educational institutions (Formal & Non-formal) to setup and run quality courses in VLSI and Embedded Systems – both theory and hands-on experimentation. |
| |
| In order to facilitate the Institutions to setup and run quality education in VLSI and Embedded Systems, , is offering a Configurable and Scalable solutions to meet the “Value for Money” requirements of typical VLSI Laboratory. |
| |
|
Technical Specification of LeaD-FPGA200: |
| 1 |
Supports Xilinx Spartan2 & Spartan3 FPGAs |
| 2 |
Unlimited re programmable support using download/ JTAG cable |
| 3 |
Supports VHDL, Verilog, Mixed HDL languages |
| 4 |
Frequency Support |
| |
|
Ext Oscillator 16 MHz, upgradable to 80 MHz. |
|
Internal frequency up to 150MHz |
|
| 5 |
The Advanced FPGA platforms are suitably buffered for I/O operations of real world signals of 5volts and 3.3 volts. |
| |
|
On board 8 Switch input and 8 LED o/ps |
|
Two Seven Segment LEDs |
|
| 6 |
Extension connectors |
| 7 |
o 26-pin – 1 no |
| 8 |
o 50-pin – 2 nos |
| 9 |
Supports all CICT’s external Real Time Interfaces (DIO, AIO) |
| 10 |
All the advanced development boards are bundled with IP cores of advanced projects and Experiments |
| |
|
|
| Note: Higher Capacity (Gates) FPGA platforms upto 4 million are available on request |
| |
| |
